A Tool to Compare Two Images of Identical Shapes

While mostly an internal tool, it does show how one can combine multiple scenes, all sharing the same data to display it different ways.

It shows a grid with 4 images: - Top Left: Reference image - Top Right: Image to compare - Bottom Left: Difference between the images (RGB) - Bottom Right: Difference between the images (Alpha)

One can pan and zoom, as well as adjust the contrast of the images.

This example can be used as an example of how a custom shader can be created in order to discard pixels based on their color.

import argparse
import sys
import os
from pathlib import Path

import imageio.v3 as imageio
import numpy as np
from imgui_bundle import imgui
from rendercanvas.auto import RenderCanvas, loop
from wgpu.utils.imgui import ImguiRenderer

import pygfx as gfx
from pygfx.renderers.wgpu import register_wgpu_render_function
from pygfx.renderers.wgpu.shaders.imageshader import ImageShader

if "PYTEST_CURRENT_TEST" not in os.environ:
    parser = argparse.ArgumentParser(description="Image Comparison")
    # Require two optional arguements
    parser.add_argument("images", nargs="*", help="The two images to compare")
    args = parser.parse_args()


if "PYTEST_CURRENT_TEST" in os.environ or len(args.images) == 0:
    # Cannot use __file__ since sphinx-gallery does not support it
    this_file = sys.argv[0]
    gfx_examples_screenshot_dir = (
        Path(this_file).parent.parent / "screenshots"
    ).resolve()
    reference = imageio.imread(
        gfx_examples_screenshot_dir / "validate_blend_weighted.png"
    )
    image = imageio.imread(gfx_examples_screenshot_dir / "validate_blend_dither.png")
elif len(args.images) == 2:
    reference = imageio.imread(args.images[0])
    image = imageio.imread(args.images[1])
else:
    print("Please provide two images to compare")
    sys.exit(1)

if image.shape != reference.shape:
    print("Image shapes do not match")
    sys.exit(1)

if image.dtype != reference.dtype:
    print("Image dtypes do not match")
    sys.exit(1)

if image.dtype.name != "uint8":
    print("Only uint8 images are supported (for now)")
    sys.exit(1)

difference_rgb = np.abs(
    image[..., :3].astype(int) - reference[..., :3].astype(int)
).astype(image.dtype)

if image.shape[-1] == 4:
    difference_alpha = np.abs(
        image[..., 3].astype(int) - reference[..., 3].astype(int)
    ).astype(image.dtype)
else:
    difference_alpha = np.zeros_like(image)

canvas_size = 800, 800

canvas = RenderCanvas(size=canvas_size)
renderer = gfx.renderers.WgpuRenderer(canvas)

w, h = canvas.get_logical_size()

viewport_reference = gfx.Viewport(renderer, rect=(0, 0, w // 2, h // 2))
viewport_image = gfx.Viewport(renderer, rect=(w // 2, 0, w - w // 2, h // 2))
viewport_diff_rgb = gfx.Viewport(renderer, rect=(0, h // 2, w // 2, h - h // 2))
viewport_diff_alpha = gfx.Viewport(
    renderer, rect=(w // 2, h // 2, w - w // 2, h - h // 2)
)

scene = gfx.Scene()
camera = gfx.OrthographicCamera(w // 2, h // 2)
camera.local.scale_y = -1

image_material = gfx.ImageBasicMaterial(clim=(0, 255))

diff_material = gfx.ImageBasicMaterial(
    clim=(0, max(difference_alpha.max(), difference_rgb.max(), 1))
)

geometry_reference = gfx.Geometry(grid=gfx.Texture(reference[..., :3], dim=2))
geometry_image = gfx.Geometry(grid=gfx.Texture(image[..., :3], dim=2))
geometry_diff_rgb = gfx.Geometry(grid=gfx.Texture(difference_rgb, dim=2))
geometry_diff_alpha = gfx.Geometry(grid=gfx.Texture(difference_alpha, dim=2))

gfx_reference = gfx.Image(geometry_reference, image_material)
gfx_image = gfx.Image(geometry_image, image_material)


# We create a dedicated pixel peeper shader which will cause "0" differences
# to be discareded
class ImageErrorOverlay(gfx.Image):
    pass


@register_wgpu_render_function(ImageErrorOverlay, gfx.ImageBasicMaterial)
class ErrorOverlayShader(ImageShader):
    def get_code(self):
        # Note that we provide no guarantees on the continuity of the shader code
        # using text manipulation like this is not guaranteed to work as part
        # of our API.
        # we would typically recommend that users build up their own objects
        # and shaders.
        return (
            super()
            .get_code()
            .replace(
                """
    let out_color = vec4<f32>(physical_color, opacity);
""",
                """
    let out_color = vec4<f32>(physical_color, opacity);
    if (length(out_color.rgb) < 1e-3) {
        discard;
    }
""",
            )
        )


gfx_reference_overlay_rgb = ImageErrorOverlay(geometry_diff_rgb, diff_material)
gfx_reference_overlay_rgb.local.z = 1
gfx_reference_overlay_rgb.visible = False

gfx_image_overlay_rgb = ImageErrorOverlay(geometry_diff_rgb, diff_material)
gfx_image_overlay_rgb.local.z = 1
gfx_image_overlay_rgb.visible = False

gfx_reference_overlay_alpha = ImageErrorOverlay(geometry_diff_alpha, diff_material)
gfx_reference_overlay_alpha.local.z = 1
gfx_reference_overlay_alpha.visible = False

gfx_image_overlay_alpha = ImageErrorOverlay(geometry_diff_alpha, diff_material)
gfx_image_overlay_alpha.local.z = 1
gfx_image_overlay_alpha.visible = False

scene_reference = gfx.Scene()
scene_reference.add(gfx.Background.from_color("#111111"))
scene_reference.add(gfx_reference)
scene_reference.add(gfx_reference_overlay_rgb)
scene_reference.add(gfx_reference_overlay_alpha)

scene_image = gfx.Scene()
scene_image.add(gfx.Background.from_color("#111111"))
scene_image.add(gfx_image)
scene_image.add(gfx_image_overlay_rgb)
scene_image.add(gfx_image_overlay_alpha)

gfx_diff_rgb = gfx.Image(geometry_diff_rgb, diff_material)
gfx_diff_alpha = gfx.Image(geometry_diff_alpha, diff_material)

scene_diff_rgb = gfx.Scene()
scene_diff_rgb.add(gfx.Background.from_color("#111111"))
scene_diff_rgb.add(gfx_diff_rgb)

scene_diff_alpha = gfx.Scene()
scene_diff_alpha.add(gfx.Background.from_color("#111111"))
scene_diff_alpha.add(gfx_diff_alpha)


camera.show_object(scene_reference)

controller_reference = gfx.PanZoomController(camera, register_events=viewport_reference)
controller_image = gfx.PanZoomController(camera, register_events=viewport_image)
controller_diff_rgb = gfx.PanZoomController(camera, register_events=viewport_diff_rgb)
controller_diff_alpha = gfx.PanZoomController(
    camera, register_events=viewport_diff_alpha
)

gui_renderer = ImguiRenderer(renderer.device, canvas)


def draw_imgui():
    imgui.set_next_window_size((300, 0), imgui.Cond_.always)
    imgui.set_next_window_pos((0, 0), imgui.Cond_.always)

    is_expand, _ = imgui.begin("Controls", None)

    if is_expand:
        clim_min, clim_max = image_material.clim
        changed, clim_min, clim_max = imgui.drag_int_range2(
            "Images",
            int(clim_min),
            int(clim_max),
            1.0,
            0,
            255,
            "Min: %d",
            "Max: %d",
        )
        if changed:
            image_material.clim = clim_min, clim_max

        clim_min, clim_max = diff_material.clim
        changed, clim_min, clim_max = imgui.drag_int_range2(
            "Difference",
            int(clim_min),
            int(clim_max),
            1.0,
            0,
            255,
            "Min: %d",
            "Max: %d",
        )
        if changed:
            diff_material.clim = clim_min, clim_max

        changed, visible = imgui.checkbox(
            "Overlay Diff RGB", gfx_reference_overlay_rgb.visible
        )
        if changed:
            gfx_reference_overlay_rgb.visible = visible
            gfx_image_overlay_rgb.visible = visible

        changed, visible = imgui.checkbox(
            "Overlay Diff Alpha", gfx_reference_overlay_alpha.visible
        )
        if changed:
            gfx_reference_overlay_alpha.visible = visible
            gfx_image_overlay_alpha.visible = visible

        changed, swap_images = imgui.checkbox(
            "Swap Images", gfx_image.geometry != geometry_image
        )
        if changed:
            if swap_images:
                gfx_reference.geometry = geometry_image
                gfx_image.geometry = geometry_reference
            else:
                gfx_reference.geometry = geometry_reference
                gfx_image.geometry = geometry_image

    imgui.end()


def animate():
    w, h = canvas.get_logical_size()

    viewport_reference.rect = (0, 0, w // 2, h // 2)
    viewport_image.rect = (w // 2, 0, w - w // 2, h // 2)
    viewport_diff_rgb.rect = (0, h // 2, w // 2, h - h // 2)
    viewport_diff_alpha.rect = (w // 2, h // 2, w - w // 2, h - h // 2)

    viewport_reference.render(scene_reference, camera)
    viewport_image.render(scene_image, camera)
    viewport_diff_rgb.render(scene_diff_rgb, camera)
    viewport_diff_alpha.render(scene_diff_alpha, camera)

    renderer.flush()
    gui_renderer.render()
    canvas.request_draw()


gui_renderer.set_gui(draw_imgui)
if __name__ == "__main__":
    canvas.request_draw(animate)
    loop.run()
